FEATURE
- · Small size of light-weight design
- · Circuit installation for electric damage prevention
- · Stable arc by regulating the IGBT inverter
- · Easy control by using one-touch typed connection plug
- · Energy storage with low power input
- · You can weld most of steel types, such as alloy, stainless steel and cast iron, etc
- · Fine welding bead is available
SPECIFICATIONS
MODEL | DRAGUN 180 | DRAGUN 230 |
Rated input voltage | Siingle 220V | Single 220V |
Frequency | 50/60Hz | 50/60Hz |
Power consumption | 5.0KW | 7KW |
Rated output current | 30~180A | 40~200A |
Load voltage | 24.8V | 24.8V |
Max. no-load voltage | <15V | <15V |
Duty cycle | 60% | 60% |
DIMENSION(WxDxH) | 145x370x285 | 180x440x300 |
Weight | 7.2Kg | 12Kg |
